Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-75S
$91.41
Regular price
$98.91
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQJ50X100-75S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQJ50~63 Adjustable Compact Cylinder
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
Installation tip:
When adjusting stroke, loosen lock nut completely before turning adjustment screw.
Apply Loctite 243 to threads after final position setting. Maintain 0.5mm minimum
cushion overlap at stroke ends to prevent impact damage.
1. Complies with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, with riveted piston-rod connection for compact and reliable construction;
3. Precision-honed inner bore ensures superior wear resistance and long-term durability;
4. Extended front cover guide length enhances directional stability;
5. Space-saving profile minimizes installation footprint;
6. Perimeter sensor slots enable effortless sensor integration;
7. Multiple mounting accessory configurations available.
Category: Compact Cylinder | Brand: AIRTAC | Series: ACQJ50~63
AirTAC ACQJ50X100-75S Adjustable Compact Cylinder Specifications
- Model Series: ACQJ50~63 (Cylinder bore 50mm to 63mm)
- Specific Model: ACQJ50X100-75S
- Bore Size: 50mm (ISO standard)
- Stroke: 100mm (Max adjustable range: ±5mm via built-in stopper)
- Adjustment Mechanism: External screw-type stroke adjustment (75S suffix indicates 75mm effective adjustment range)
- Operating Pressure: 0.1~0.9 MPa
- Temperature Range: -20℃ to 80℃ (with NBR seals)
- Cushioning: Dual adjustable rubber buffers
- Mounting Style: Basic type (No pre-mounted brackets) with MF1 and MF2 optional flange patterns
- Port Size: M5x0.8 (Standard) / Optional NPT1/8
- Piston Material: Hard anodized aluminum alloy
- Rod Material: Chrome-plated steel (Cr-Mo steel base)
- Seal Type: High wear-resistant NBR with dust wiper
- Weight: 1.45kg (Without accessories)
- Dimensions:
- Body Length: 156mm (Minimum retracted length)
- Width: 64mm (Across mounting surfaces)
- Height: 50mm (Including rod end)
- Rod Thread: M10x1.25 (External)
Ultra-slim profile cylinder (50mm height) with precision stroke adjustment capability, designed for space-constrained automation systems. Features anti-rotation piston rod and dual-position sensing slots for magnetic switch installation (SM/SMF series compatible). Optional auto switch bracket available for DIN rail mounting.
Typical Applications:
- PCB handling robots requiring millimeter-level positioning
- Pharmaceutical blister packaging machines
- Glass panel press mechanisms with fine stroke control
- Semiconductor wafer transfer systems
- Automated test equipment (ATE) fixture actuation
Installation tip:
When adjusting stroke, loosen lock nut completely before turning adjustment screw.
Apply Loctite 243 to threads after final position setting. Maintain 0.5mm minimum
cushion overlap at stroke ends to prevent impact damage.
| Property | Property Value |
|---|---|
| sku | ACQJ50X100-75S |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
