AirTAC SAI Series · ISO 15552 Cylinder

Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-100S

The AirTAC Adjustable Cylinder SAIJ32 SAIJ32X100-100S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ32 mm
  • Stroke100 mm
  • Port sizeG1/8
  • Acting typeDouble acting
  • Rod threadM10×1.25
  • CushionAdjustable, 27 mm
$66.03 $73.53Save 10% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ32 stroke, mounting and version on one page All SAIJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-100S

The AirTAC SAIJ32X100-100-S is a double-acting ISO 15552 profile cylinder equipped with a rear stroke adjuster, allowing you to dial back the nominal 100 mm travel to anywhere in a 0-100 mm usable window.

This variant includes a magnet for CMSE reed and DMSE electronic sensors, utilizing the dual sensor grooves machined into the extruded aluminum barrel. It features a 12 mm carbon steel rod with an M10x1.25 thread, and uses a PT tapered G1/8 port. The SAIJ mounting set omits FB, CA, CB, and CR options, supporting Basic, FA, LB, TC, FTC, TCM1, and TCM2 attachments.

Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-100S Technical Specifications

ModelAirtac Adjustable Cylinder SAIJ32 SAIJ32X100-100S
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ32 mm
Stroke100 mm
Acting typeDouble acting
Port sizeG1/8
Rod threadM10×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm
Max strokeUp to 1000 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa346 N346 N
0.7 MPa484 N—
Max (@1.0 MPa)70 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-100S

SAIISO 15552 profile-barrel cylinder series.
32Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-100S Is Used

tune

Variable End-Stop Tuning

Dial in the exact retract position from 0 to 100 mm during commissioning to accommodate varying product sizes without adding external stopper blocks.

settings_input_component

Machine Changeover

Rapidly adjust the effective stroke on packaging lines when switching between different package lengths, minimizing downtime.

Is the Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-100S the Right Cylinder?

The rear adjuster screw acts purely as a mechanical stop to fine-tune the retract end; it does not lock the load. For true fail-safe load holding without live air pressure, consider the SAIL or BSAI series instead.

When replacing an ISO 15552 cylinder, match the 32 mm bore, 100 mm nominal stroke, 100 mm adjustment range, PT G1/8 port, and the -S magnet requirement. Because the stroke is 100 mm, side loads are minimal, but always ensure the M10x1.25 rod thread is aligned to prevent binding during the adjustable travel window.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-100S FAQ

The rear adjuster screw allows you to mechanically shorten the effective travel from 100 mm down to 0 mm, creating a 0-100 mm usable window. This stopper only sets the end position and does not lock the load without live air.
