Airtac AFC Combination Unit AFC15001
2、Integrated self-locking mechanism prevents undesired pressure setting adjustments from external interference;
3、Minimal pressure drop with high drainage efficiency;
4、Transparent sight glass enables visual monitoring of lubricant drip rate;
5、Available in standard configuration or low-pressure variant (maximum adjustable pressure 0.4MPa).
Category: FRL Combination Units , Brand: Airtac , Series: AFC
AirTAC AFC15001 Air Filter Regulator Combination Unit Specifications
- Model: AFC15001
- Type: Filter regulator (F.R.L) combination with bracket
- Filter rating: 5μm (replaceable element)
- Adjustment range: 0.05-0.85 MPa
- Max pressure: 1.0 MPa
- Flow capacity: 3000 L/min (ANR)
- Port size: PT1/2 (G1/2 optional)
- Pressure gauge: 1/8" BSP dial type (0-1.0 MPa scale)
- Drain type: Manual drain with anti-splash guard
- Body material: Die-cast aluminum (anodized)
- Seal material: NBR & polyurethane
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.65 kg (with bracket)
- Dimensions: 160mm(W) × 150mm(H) × 95mm(D)
- Thread torque: 15-20 N·m (port connections)
Compact dual-function unit combining 5μm particulate filtration and precision pressure regulation. Features a maintenance-friendly bowl design with visible dirt accumulation indicator. The integrated bracket allows vertical or horizontal mounting. Includes a shock-resistant gauge with ±2% accuracy and silicone dampened adjustment knob.
- Pneumatic tool air supply stations
- Production line cylinder control systems
- Textile machinery air preparation
- Food processing pneumatic circuits
- Semiconductor manufacturing equipment
Installation note:
Install downstream of lubricators if used. Maintain minimum 300mm distance from heat sources.
Replace filter element when bowl contamination reaches 80% visibility. Perform monthly drain
operation under pressure for optimal performance.
| Property | Property Value |
|---|---|
| sku | AFC15001 |
| Port Size | PT1/8 |
