Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC20B-02-N-A
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC20B-02-N-A F.R.L Unit Technical Details
- Model: AC20B-02-N-A
- Type: Filter-Regulator-Lubricator (F.R.L) combination unit
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.15–0.8 MPa
- Filtration grade: 5μm (with auto-drain option)
- Pressure regulation range: 0.05–0.85 MPa
- Oil cup capacity: 50ml (max)
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR rubber
- Temperature range: -20℃ to 70℃
- Weight: 0.8kg (dry)
- Dimensions: 200mm(L) × 100mm(W) × 120mm(H)
- Flow capacity: 1,500 NL/min
Modular triple-function unit combining precision filtration (40μm stainless steel mesh), pressure regulation (±0.2% accuracy), and adjustable lubrication (2-3 drops/min). Features transparent polycarbonate bowls with anti-static coating and manual drain. Integrated mounting bracket allows vertical/horizontal installation.
- Pneumatic tool air preparation systems
- Packaging machinery main air lines
- CNC machine tool pneumatic circuits
- Automated assembly line air supply
- Food processing equipment (oil-free version available)
Installation protocol:
Install in sequence (Filter → Regulator → Lubricator) with minimum 300mm
straight inlet piping. Drain bowl requires weekly maintenance in humid
environments. Lubricant viscosity: ISO VG32 or equivalent.
| Property | Property Value |
|---|---|
| sku | AC20B-02-N-A |
| Port Size | <1/4"> |
