Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC20B-02-S-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC20B-02-S-B Triple Unit (FRL) Specifications
- Model: AC20B-02-S-B
- Type: Filter-Regulator-Lubricator combination
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–1.0 MPa
- Filter micron rating: 40μm (5μm optional element available)
- Pressure gauge range: 0–1.6 MPa (liquid-filled)
- Adjustment knob rotation: 270° with lockable setting
- Oil cup capacity: 180cm³ (visible polycarbonate bowl)
- Flow rate: 2000 NL/min (at 0.7MPa)
- Temperature range: -5℃ to 60℃ (non-freezing conditions)
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR + fluororubber hybrid
- Weight: 1.25kg (dry, without lubricant)
- Dimensions: 152mm(H) × 80mm(W) × 105mm(D)
- Drain type: Manual float drain (semi-automatic option available)
- Mounting: Bracket-slot system (ISO 4414 compliant)
- Protection rating: IP54 (bowl protection cover included)
Modular FRL unit combining 40μm particulate filtration, precision pressure regulation (with relief valve), and adjustable oil mist lubrication. Features a shock-resistant polycarbonate bowl with metal guard, anti-vibration gauge, and tool-free bowl removal. Designed for compressed air pretreatment in industrial automation systems.
- Pneumatic production line main air preparation
- CNC machine tool pneumatic systems
- Packaging machinery actuator control
- Automated assembly line tooling stations
- Industrial robot end-effector supply
Installation protocol:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below bowl for drainage access.
Lubricator should only be activated downstream of actuators requiring oil mist (5-10 drops/m³ recommended).
| Property | Property Value |
|---|---|
| sku | AC20B-02-S-B |
| Port Size | G1/4" Thread |
