Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC20C-02-T-2-A
$286.62
Regular price
$294.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
AC20C-02-T-2-A
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
● Enhanced Operational Efficiency
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
Maintenance protocol:
Install vertically with arrow marking airflow direction. Replace filter element every 2,000 operational hours.
Maintain oil level between 1/3 to 2/3 of bowl capacity. Drain condensate daily in high-humidity environments.
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC Modular FRL Unit AC20C-02-T-2-A Technical Profile
- Full model designation: AC20C-02-T-2-A (Triple Unit)
- Component configuration: Filter + Regulator + Lubricator
- Port thread: G1/4 (BSPP) with 2-M5 auto drain port
- Operating pressure range: 0.05-1.0 MPa
- Maximum flow capacity: 1,200 NL/min
- Filter element: 40μm sintered bronze (replaceable)
- Regulator accuracy: ±0.2 MPa (with lockable knob)
- Lubricator capacity: 150cc (polycarbonate bowl)
- Oil drip rate: 1-120 drops/min (adjustable)
- Temperature tolerance: -5℃ to 60℃ (non-freezing)
- Body material: Anodized aluminum alloy
- Weight: 820g ±3% (dry condition)
- Dimensions: 138mm(L) × 105mm(W) × 148mm(H)
- Pressure gauge: 63mm dial (MPa/psi dual scale)
- Seal compatibility: NBR standard (FKM optional)
- Mounting: Panel bracket or rail mountable
This integrated FRL unit combines industrial-grade filtration, precision pressure regulation, and adjustable lubrication in a space-saving package. Features anti-clog drain mechanism and impact-resistant bowl guard. The T-2 suffix indicates dual M5 pilot ports for system integration. Requires 7-12 bar compressed air input.
Implementation Scenarios:
- Pneumatic tool stations in automotive assembly lines
- Packaging machinery requiring consistent actuator performance
- CNC machine air preparation systems
- Plastic injection molding equipment
- Food processing pneumatic circuits (using food-grade oil)
- Semiconductor manufacturing cleanrooms (with optional PTFE seals)
Maintenance protocol:
Install vertically with arrow marking airflow direction. Replace filter element every 2,000 operational hours.
Maintain oil level between 1/3 to 2/3 of bowl capacity. Drain condensate daily in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | AC20C-02-T-2-A |
| Port Size | <1/4"> |
