Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC20C-02G-SV1-2-A
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC20C-02G-SV1-2-A Triple Unit (FRL) Technical Details
- Full model: AC20C-02G-SV1-2-A
- Type: Compact combination FRL (Filter-Regulator-Lubricator)
- Port size: G1/4 (BSPP thread)
- Operating pressure range: 0.05–0.9 MPa
- Maximum flow: 1,000 L/min (ANR)
- Filter rating: 5 μm (replaceable sintered element)
- Pressure gauge: 1.5" dial with anti-vibration liquid
- Adjustment knob: Lockable rotary type with ±0.2% hysteresis
- Lubricator capacity: 100 cc (oil viscosity ISO VG32-68)
- Drain type: Manual push-button with anti-drip shield
- Body material: Anodized aluminum alloy
- Seals: NBR (standard), optional FKM
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 650 g ±3%
- Dimensions: 180mm(H) × 70mm(W) × 70mm(D)
Modular FRL unit combining 40μm pre-filter, precision pressure regulator, and adjustable micro-oiler in vertical stack configuration. Features bubble-tight shutoff and automatic pressure holding with <0.05 MPa leakage. Integrated mounting slots allow panel or rail installation. Maximum air velocity: 20 m/s.
- Pneumatic tool stations requiring clean lubricated air
- Production line actuator clusters (robotic arms, clamps)
- CNC machine air preparation systems
- Food packaging machinery (dry process zones)
- Semiconductor handling equipment
Maintenance protocol:
Replace filter element every 2,000 operational hours or when differential pressure exceeds 0.1 MPa.
Lubricator refill interval: 8-12 weeks under normal use (8hrs/day). Always purge air before adjusting regulator.
| Property | Property Value |
|---|---|
| sku | AC20C-02G-SV1-2-A |
| Port Size | <1/4"> |
