Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC20C-02G-SV1-R-A
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC20C-02G-SV1-R-A Triple Unit (F.R.L.) Specifications
- Model: AC20C-02G-SV1-R-A
- Type: Filter-Regulator-Lubricator Combination
- Port size: G1/4 (BSPP thread)
- Operating pressure range: 0.05–1.0 MPa
- Maximum pressure: 1.5 MPa
- Filtration grade: 5 μm (auto-drain version)
- Regulator accuracy: ±0.2 bar
- Lubricator oil capacity: 180 cm³
- Air flow capacity: 2,500 L/min (ANR)
- Weight: 1.8 kg (with oil)
- Dimensions: 200mm(W) × 165mm(H) × 85mm(D)
- Body material: Die-cast aluminum (filter bowl: polycarbonate)
- Seal material: NBR/HNBR
- Temperature range: -5℃ to 60℃ (non-freezing)
- Pressure gauge: 1/8" dial type (0–1.6 MPa scale)
- Mounting: Bracket or direct piping
Industrial-grade air preparation unit combining particulate filtration (5μm), precision pressure regulation (±0.2 bar stability), and adjustable lubrication. Features a transparent bowl with auto-drain (manual drain optional), impact-resistant polycarbonate filter housing, and corrosion-resistant aluminum body. The SV1 suffix indicates a vertical pressure gauge orientation with Rc1/8 thread ports.
- Pneumatic production line main air conditioning
- CNC machine tool pneumatic systems
- Automated assembly equipment
- Packaging machinery air supply treatment
- Industrial robot end-effector control
Installation protocol:
Install in sequence Filter → Regulator → Lubricator with minimum 300mm straight inlet piping.
Maintain vertical orientation of lubricator bowl. Drain condensate daily in high-humidity environments.
Recommended maintenance: Replace filter element every 2,000 operational hours.
| Property | Property Value |
|---|---|
| sku | AC20C-02G-SV1-R-A |
| Port Size | <1/4"> |
