Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC25-02D-A
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC25-02D-A FRL Combination Unit Technical Details
- Model: AC25-02D-A (Triple Unit)
- Configuration: Filter + Regulator + Lubricator
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Filtration grade: 50μm (5μm optional element available)
- Pressure gauge: 1/8" dial type (0-1.6 MPa range)
- Adjustment knob: Lockable rotary design
- Oil capacity: 100cm³ (visible oil bowl)
- Flow rate: 2,500 NL/min (at 0.7MPa)
- Weight: 0.68 kg (1.5 lbs)
- Dimensions: 145mm(W) × 105mm(H) × 85mm(D)
- Body material: Anodized aluminum alloy
- Seals: NBR (Nitrile rubber)
- Temperature range: 5℃ to 60℃ (non-freezing)
- Drain type: Manual float drain
Integrated compressed air treatment unit combining precision filtration (with water separator), pressure regulation with tamper-proof adjustment, and adjustable oil mist lubrication. Features a transparent polycarbonate bowl with anti-burst shield and pressure relief safety valve. The regulator includes a T-handle with push-lock mechanism for stable pressure maintenance.
- Pneumatic production line header systems
- CNC machine tool air preparation
- Automotive assembly line tool stations
- Packaging machinery air circuit conditioning
- Textile machinery lubrication systems
Installation protocol:
Install vertically with flow arrow alignment. Maintain 200mm clearance below drain port.
Lubricator should operate at 1/800~1/1000 oil feed ratio. Replace filter element every 4,000 hours
in normal conditions. Use ISO VG32 turbine oil for lubrication.
| Property | Property Value |
|---|---|
| sku | AC25-02D-A |
| Port Size | <1/4"> |
