Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC25-03-R-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC25-03-R-B Triple Unit (FRL) Specifications
- Model: AC25-03-R-B
- Type: Filter-Regulator-Lubricator combination
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–0.85 MPa
- Filtration grade: 5μm (40μm optional element available)
- Lubricator oil capacity: 35cc (max)
- Pressure gauge range: 0–1.0 MPa
- Temperature range: 5℃ to 60℃ (non-freezing)
- Body material: Aluminum alloy (filter bowl: polycarbonate)
- Weight: 0.8kg ±5% (dry)
- Dimensions: 150mm(H) × 100mm(W) × 120mm(D)
- Pressure adjustment knob torque: 0.3–0.5 N·m
- Drain type: Manual float drain
Integrated compressed air treatment unit featuring corrosion-resistant construction with visible bowl design. The modular assembly includes 360° rotatable gauge and tool-free bowl removal. The regulator maintains ±5% output stability under fluctuating input pressures. Requires ISO VG32 turbine oil for lubrication.
- Pneumatic tool stations in automotive workshops
- Packaging machinery air line conditioning
- Robotic arm pneumatic circuits
- Textile machinery lubrication systems
- Food processing plant air preparation (with optional NSF-certified bowl)
Installation protocol:
Install in sequence F→R→L with minimum 300mm straight tubing before filter inlet.
Drain bowl weekly - maximum condensate level should not exceed 80% of bowl capacity.
| Property | Property Value |
|---|---|
| sku | AC25-03-R-B |
| Port Size | 3/8" |
