Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC30-03CG-V-A
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC30-03CG-V-A Air Treatment Combination Unit Specifications
- Model: AC30-03CG-V-A
- Type: 3-in-1 Filter-Regulator-Lubricator (F.R.L.) Unit
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–1.0 MPa
- Maximum pressure: 1.5 MPa
- Filtration rating: 5 μm (auto-drain version)
- Flow capacity: 2000 L/min (ANR)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR (nitrile rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 0.82 kg
- Dimensions: 150mm(L) × 80mm(W) × 100mm(H)
- Pressure gauge: 1/8" dial type (0-1.6 MPa scale)
- Lubricator oil capacity: 60 cm³
- Mounting: Bracket integrated (panel mountable)
Modular F.R.L. unit combining 40μm pre-filter, precision pressure regulator, and adjustable oil-mist lubricator. Features manual bypass for emergency operation and transparent bowl with anti-splash design. The regulator includes a T-handle with lockable pressure setting and dual metric/imperial gauge markings.
- Pneumatic tool air preparation systems
- CNC machine pneumatic circuits
- Automated assembly line main air supply
- Packaging machinery air conditioning
- Industrial robot end-effector support
Installation note:
Install within 10 meters downstream of compressor. Maintain vertical orientation of lubricator section.
Drain bowl requires weekly maintenance in high-humidity environments. Use ISO VG32 turbine oil for lubrication.
| Property | Property Value |
|---|---|
| sku | AC30-03CG-V-A |
| Port Size | 3/8" |
