Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC30B-02-1-A
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC Modular 3-in-1 Unit AC30B-02-1-A Specifications
- Model: AC30B-02-1-A
- Type: FRL Unit (Filter-Regulator-Lubricator)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–0.9 MPa
- Max flow rate: 300 L/min (ANR)
- Filter element: 40μm sintered bronze
- Adjustable pressure range: 0.05–0.85 MPa
- Lubricator oil capacity: 200ml
- Body material: Aluminum alloy (anodized)
- Seal material: NBR
- Temperature range: -20℃ to 60℃
- Weight: 0.6kg (dry)
- Dimensions: 120mm(L) × 70mm(W) × 110mm(H)
- Pressure gauge: 0.1–1.0 MPa dial (Ø32mm)
- Drain type: Manual float drain
Compact modular FRL unit combining air preparation functions with space-saving design. Features a corrosion-resistant aluminum body with integrated pressure gauge and ergonomic adjustment knob. The transparent polycarbonate bowl allows visual inspection of filter contamination and oil level. Requires upstream installation of shut-off valve for maintenance.
- Pneumatic automation lines in electronics assembly
- Packaging machinery air preparation systems
- CNC machine tool pneumatic circuits
- Automotive production line tooling stations
- Woodworking air tool supply systems
Installation protocol:
Install in sequence (Filter → Regulator → Lubricator) with minimum 300mm
straight tubing upstream. Replace filter element every 3 months under
normal conditions (ISO 8573-1 class 4 air quality). Avoid direct sunlight
exposure to prevent bowl discoloration.
| Property | Property Value |
|---|---|
| sku | AC30B-02-1-A |
| Port Size | <1/4"> |
