Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC30B-02-R-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC30B-02-R-B Triple Unit (FRL) Specifications
- Model: AC30B-02-R-B
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT1/4 (G1/4)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 1,500 L/min (ANR)
- Filtration level: 50 μm (with auto-drain)
- Regulator accuracy: ±0.2 bar
- Oil cup capacity: 80 cm³ (transparent polycarbonate)
- Weight: 1.2 kg (with bracket)
- Dimensions: 155mm(W) × 160mm(H) × 85mm(D)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Body material: Die-cast aluminum (anodized)
- Seal material: NBR + Fluororubber hybrid
- Pressure gauge: 1/8" BSPT interface, 0-1.6 MPa range
Modular air preparation unit integrating precision filtration (with manual/auto drain options), pressure regulation with lockable knob, and adjustable lubricator. Features tool-free bowl removal and a debris-resistant filter element. Designed for industrial environments requiring stable air quality control.
- Pneumatic assembly line systems
- CNC machine tool air supply
- Packaging machinery air circuits
- Automotive painting systems
- Food processing pneumatic controls (oil-free version available)
Installation note:
Mount vertically with arrow direction matching airflow. Maintain 50mm clearance below drain port.
Lubricator should be filled to 60% capacity and adjusted to 1 drop/5-10m³ air. Replace filter element
when pressure drop exceeds 0.05 MPa.
| Property | Property Value |
|---|---|
| sku | AC30B-02-R-B |
| Port Size | G1/4" Thread |
