Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC30B-03-R-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC Series Triple Unit AC30B-03-R-B Technical Details
- Model: AC30B-03-R-B
- Type: Filter-Regulator-Lubricator (FRL) combination
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 1,500 L/min (ANR)
- Filtration grade: 40μm (replaceable sintered filter element)
- Pressure gauge: 1/8" BSPT dial type (0-1.6 MPa range)
- Lubricator oil capacity: 80cm³ (with drip rate control knob)
- Operating temperature: 5℃ to 60℃ (non-freezing)
- Body material: Aluminum alloy (anodized surface)
- Weight: 0.85kg (dry, without lubricant)
- Dimensions: 150mm(H) × 70mm(W) × 70mm(D)
- Drain type: Manual float drain
- Thread compatibility: ISO 228/1 standard
Modular FRL unit combining precision air preparation functions with tool-free maintenance features. The corrosion-resistant design includes a transparent polycarbonate bowl with safety shield, allowing visual monitoring of filter contamination. The integrated bypass mechanism prevents pressure spikes during regulator adjustment.
- Pneumatic production line main air supply conditioning
- CNC machine tool pneumatic systems
- Automated assembly line actuator control
- Packaging machinery air circuit protection
- Robotic arm pneumatic supply stations
Installation protocol:
Install in sequence (filter → regulator → lubricator) with minimum 300mm straight inlet piping.
Lubricator should be positioned at least 500mm downstream from actuators. Replace filter element
when pressure drop exceeds 0.1MPa.
| Property | Property Value |
|---|---|
| sku | AC30B-03-R-B |
| Port Size | G3/8 |
