Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC30B-N03-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC30B-N03-B Triple Unit (FRL) Specifications
- Model: AC30B-N03-B
- Type: Filter-Regulator-Lubricator combination
- Port size: PT1/4 (G1/4 optional)
- Maximum pressure: 1.5 MPa
- Filter rating: 5μm (with auto-drain)
- Pressure gauge: 1/8" BSPT dial (0-1.0 MPa scale)
- Adjustment range: 0.05-0.85 MPa
- Drain type: Semi-automatic float drainage
- Body material: Aluminum alloy (anodized)
- Seal material: NBR/PU
- Temperature range: -5℃ to 60℃
- Protection rating: IP42
- Weight: 1.2 kg ±5%
- Dimensions: 180mm(L) × 70mm(W) × 120mm(H)
Compact modular FRL unit with integrated pressure regulation and micro-mist lubrication. Features a transparent polycarbonate bowl with safety shield and anti-backflow design. The dual-chamber filter element provides 98.5% water separation efficiency. Includes a tamper-proof adjustment knob with lockable pressure setting.
- Pneumatic tool air preparation systems
- Packaging machinery main air lines
- Automated assembly line pneumatic circuits
- CNC machine tool lubrication systems
- Food processing pneumatic controls (oil-free option available)
Maintenance note:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.1 MPa.
Bowl torque specification: 3.5-4.0 N·m during reassembly. Install vertically with arrow mark facing upward.
| Property | Property Value |
|---|---|
| sku | AC30B-N03-B |
| Port Size | 3/8" |
