Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC40-03DG-A
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC40-03DG-A Air Treatment Combination Unit Specifications
- Model: AC40-03DG-A
- Type: Filter-Regulator-Lubricator (FRL) combination
- Port size: PT1/2 (G1/2 optional)
- Max operating pressure: 1.6 MPa
- Pressure regulation range: 0.05-0.85 MPa
- Flow capacity: 3,500 L/min (ANR)
- Filter micron rating: 5μm (40μm optional element available)
- Pressure gauge range: 0-1.0 MPa (Glycerin-filled optional)
- Weight: 2.3 kg (with bracket)
- Dimensions: 180mm(W) × 155mm(H) × 110mm(D)
- Body material: Die-cast aluminum (anodized finish)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Manual/auto drain optional
- Oil droplet size: 5-7μm (adjustable lubricator)
Industrial-grade FRL unit featuring corrosion-resistant construction and precision pressure stabilization. The modular design allows individual component replacement. The transparent bowl with metal guard enables visual contamination monitoring. Includes pressure relief vent for safe adjustment.
- Pneumatic system pretreatment in CNC machines
- Assembly line actuator control systems
- Packaging machinery air preparation
- Industrial robot end-effector supply
- Plastic injection molding air circuits
Installation guidelines:
Mount vertically with airflow arrow alignment. Maintain 50mm clearance below drain port.
Replace filter element every 2,000 operational hours in standard environments.
Not recommended for steam or aggressive chemical gases.
| Property | Property Value |
|---|---|
| sku | AC40-03DG-A |
| Port Size | 3/8" |
