Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC40-04E-1-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC40-04E-1-B Air Treatment Combination Unit Specifications
- Model: AC40-04E-1-B
- Type: 3-in-1 FRL unit (Filter-Regulator-Lubricator)
- Thread size: PT1/2 (G1/2 optional)
- Max flow capacity: 2,500 L/min
- Operating pressure range: 0.05–1.0 MPa
- Filtration rating: 40μm (5μm optional element)
- Pressure gauge: 1/8" BSP dial gauge (0-1.6 MPa scale)
- Adjustment knob: Lockable rotary type with ±2% accuracy
- Weight: 1.85 kg (with bracket)
- Dimensions: 190mm(L) × 165mm(W) × 195mm(H)
- Body material: Die-cast aluminum (anodized finish)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Oil drip rate: 1-120 drops/min adjustable
- Drain type: Manual push-button with auto-drain option
Industrial-grade FRL unit featuring triple-stage air preparation with visual pressure feedback. The corrosion-resistant design includes a bowl guard and impact-resistant polycarbonate bowl. Integrated mounting slots allow 180° rotation for flexible piping layouts. Requires 5-8 bar compressed air input.
- Pneumatic production line main air supply
- CNC machine tool pneumatic systems
- Automated assembly line actuators
- Packaging machinery air circuit control
- Robotic arm pneumatic tooling
Maintenance tip:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.1 MPa.
Lubricator oil level should be maintained above 1/3 capacity. Install vertically ±15° for proper oil mist distribution.
| Property | Property Value |
|---|---|
| sku | AC40-04E-1-B |
| Port Size | 1/2" |
