Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC40A-03DG-S-A
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC Series Trio Unit AC40A-03DG-S-A Full Specifications
- Model: AC40A-03DG-S-A
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT1/4 (G1/4)
- Operating pressure range: 0.05–0.85 MPa
- Max flow rate: 1,500 L/min (ANR)
- Filter micron rating: 5μm (auto-drain version)
- Regulator accuracy: ±0.008 MPa
- Lubricator oil capacity: 150cm³
- Oil droplet rate: 1~3 drops/min adjustable
- Weight: 1.2kg (with bracket)
- Dimensions: 165mm(W) × 150mm(H) × 90mm(D)
- Material: Aluminum alloy body, NBR seals
- Temperature range: -5℃ to 60℃ (non-freezing)
- Protection rating: IP42 (standard)
- Mounting: Bracket included for wall/pipeline installation
A modular FRL unit integrating precision air preparation functions. Features a transparent bowl with anti-burst design, pressure gauge port, and tool-free bowl removal. The regulator includes a tamper-proof cover and memory piston for stable output. Requires ISO VG32 turbine oil for lubrication.
- Pneumatic tool stations in automotive workshops
- Production line air preparation for CNC machines
- Packaging machinery compressed air conditioning
- Industrial robot end-effector supply systems
- Food processing pneumatic circuits (oil-free option available)
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Maintain 200mm clearance below bowl for maintenance.
Drain filter daily in high-humidity environments.
Lubricator should be filled to 80% capacity maximum.
| Property | Property Value |
|---|---|
| sku | AC40A-03DG-S-A |
| Port Size | 3/8" |
