Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC40A-04D-8-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC40A-04D-8-B Triple Unit (FRL) Technical Specifications
- Model: AC40A-04D-8-B
- Type: Filter-Regulator-Lubricator combination
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow: 1,500 L/min (ANR)
- Filter rating: 40μm (5μm optional element available)
- Regulator adjustment range: 0.05–0.85 MPa
- Lubricator oil capacity: 180cc
- Weight: 0.82 kg (dry)
- Dimensions: 160mm(L) × 80mm(W) × 100mm(H)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Pressure gauge: 1/8" BSPT dial (0-1.6 MPa scale)
- Drain type: Manual float drain
Integrated FRL unit combining high-efficiency particulate filtration, precision pressure regulation, and adjustable aerosol lubrication. Features a transparent polycarbonate bowl with anti-static coating and impact-resistant metal guard. The regulator includes a T-handle for tool-free adjustment with ±2% accuracy.
- Pneumatic tool stations in automotive assembly lines
- CNC machine air preparation systems
- Packaging machinery main air supply conditioning
- Industrial robot end-effector control systems
- Plastic injection molding machine air circuits
Installation protocol:
Mount vertically with flow arrow alignment. Maintain 20cm clearance below drain port.
Lubricator should be filled with ISO VG32 or equivalent oil. Replace filter element every
2,000 operational hours or when pressure drop exceeds 0.05MPa.
| Property | Property Value |
|---|---|
| sku | AC40A-04D-8-B |
| Port Size | 1/2" |
