Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC40A-04DG-1-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC40A-04DG-1-B Triple Unit (FRL) Technical Specifications
- Model Code Breakdown: AC40A (Series) / 04 (1/4" Port) / DG (Drain Type) / 1 (Bracket Type) / B (Special Configuration)
- Port Connection: PT1/4 (BSPP) with aluminum alloy body
- Operating Pressure Range: 0.05-0.9 MPa (7-130 PSI)
- Filter Element: 40μm sintered stainless steel (replaceable)
- Pressure Gauge: 1.5" dial with glycerin damping, 0-1.6 MPa scale
- Lubricator Adjustment: 0-180 drops/min with visible oil window
- Drain Type: Manual drain with anti-splash shield
- Maximum Flow Rate: 1,500 NL/min (ANR)
- Temperature Range: -5℃ to 60℃ (non-freezing conditions)
- Weight: 1.2 kg (with bracket, empty lubricator)
- Dimensions: 180mm(H) × 80mm(W) × 150mm(D)
- Material: Aluminum alloy (filter/regulator), PC bowl (impact-resistant)
- Thread Seal: PTFE tape compatible with NPT threads
Integrated FRL (Filter-Regulator-Lubricator) unit with enhanced moisture separation efficiency (98% @ 0.7MPa). Features a tamper-proof pressure regulator with lockable knob and dual-scale (bar/psi) gauge. The transparent polycarbonate bowl includes a safety shield and maximum pressure mark. Designed for industrial duty cycles with 500,000+ actuations MTBF.
- Pneumatic production lines requiring clean lubricated air
- CNC machine tool pneumatic systems
- Packaging machinery with multiple actuators
- Food processing equipment (food-grade oil compatible)
- Automated assembly line main air prep
Maintenance Protocol:
Drain filter daily in high-humidity environments. Refill lubricator with ISO VG32 or equivalent oil.
Replace filter element every 2,000 operating hours. Mount vertically with arrow ↑ marking airflow direction.
| Property | Property Value |
|---|---|
| sku | AC40A-04DG-1-B |
| Port Size | 1/2" |
