Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC40A-04G-R-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC Modular FRL Unit AC40A-04G-R-B Technical Specifications
- Full model designation: AC40A-04G-R-B
- Configuration: 3-in-1 modular FRL (Filter-Regulator-Lubricator)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–0.85 MPa
- Maximum flow capacity: 2000 L/min
- Filter element rating: 40μm precision
- Water bowl capacity: 15cc (manual drain)
- Lubricator oil capacity: 100cc (transparent polycarbonate bowl)
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR (Nitrile rubber)
- Temperature tolerance: -5℃ to 60℃
- Weight: 1.25kg (complete assembly)
- Dimensions: 180mm(H) × 120mm(W) × 85mm(D)
- Pressure gauge range: 0–1.0 MPa (integrated dual scale bar/kPa)
- Protection class: IP40 (non-hazardous environments)
All-in-one compressed air conditioning unit combining particulate filtration, pressure regulation, and precision lubrication. Features a corrosion-resistant modular design with visible bowl indicators and tool-free bowl removal. The integrated bypass mechanism maintains airflow during filter maintenance. Requires upstream installation of a shut-off valve for service operations.
- Centralized pneumatic system pretreatment
- CNC machine tool pneumatic circuits
- Automated assembly line actuator systems
- Industrial robotic end-effector control
- Packaging machinery air preparation
Installation protocol:
Install in sequence: Filter → Regulator → Lubricator (vertical orientation required).
Maintain minimum 50cm downstream pipe length after lubricator for proper oil mist dispersion.
Drain bowl daily in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | AC40A-04G-R-B |
| Port Size | 1/2" |
