Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC40B-03-N-B
$256.64
Regular price
$264.14
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
AC40B-03-N-B
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
● Enhanced Operational Efficiency
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below bowl for drainage access.
Lubricator should be positioned after filter-regulator in airflow path.
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC40B-03-N-B FRL Combination Unit Specifications
- Model: AC40B-03-N-B
- Type: Filter-Regulator-Lubricator (FRL) with pressure gauge
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.05–0.85 MPa
- Maximum flow: 2500 L/min
- Filter micron rating: 5μm (40μm optional element available)
- Adjustable lubrication: 0–10 drops/min
- Weight: 1.2kg (with bracket)
- Dimensions: 180mm(L) × 80mm(W) × 120mm(H)
- Bowl material: Polycarbonate (metal bowl optional)
- Seal material: NBR (Viton available on request)
- Temperature range: 0℃ to 60℃ (non-freezing)
- Pressure gauge: 63mm dial, 0-1.0MPa range
- Drain type: Manual drain with anti-splash shield
Modular air preparation unit combining precision filtration, pressure regulation, and adjustable lubrication. Features a visible bowl design with impact-resistant polycarbonate construction and ergonomic pressure adjustment knob. Includes a tamper-proof lock nut for preset pressure maintenance.
Typical Applications:
- Pneumatic tool air supply systems
- Production line actuator control stations
- CNC machine pneumatic circuits
- Packaging machinery air preparation
- Industrial robot end-effector supply lines
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below bowl for drainage access.
Lubricator should be positioned after filter-regulator in airflow path.
Maintenance cycle:
Drain bowl daily under normal operation (hourly in high-humidity environments).
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.05MPa.
| Property | Property Value |
|---|---|
| sku | AC40B-03-N-B |
| Port Size | G3/8 |
