Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC40B-04E-R-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC40B-04E-R-B Triple Unit (FRL) Specifications
- Model: AC40B-04E-R-B
- Type: Filter-Regulator-Lubricator combination
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–1.0 MPa
- Maximum flow: 1,200 L/min
- Filter rating: 5 μm (40 μm optional element available)
- Lubricator oil capacity: 180 cm³
- Pressure gauge: 1/8" dial type (0-1.6 MPa scale)
- Body material: Aluminum alloy (anodized finish)
- Seal material: HNBR (hydrogenated nitrile)
- Temperature range: -10℃ to 60℃ (with anti-freeze drain)
- Weight: 0.82 kg
- Dimensions: 145mm(W) × 85mm(D) × 175mm(H)
- Drain type: Manual float drain
- Protection rating: IP40 (standard)
Integrated air preparation unit combining precision filtration (99.9% water removal), pressure stabilization (±0.05 MPa regulation accuracy), and adjustable lubrication (0-8 drops/min). Features a corrosion-resistant bypass mechanism and shock-resistant polycarbonate bowl with metal guard. Includes built-in pressure relief valve and auto-drain safety lock.
- Pneumatic production line main air supply
- CNC machine tool pneumatic systems
- Industrial robot end-effector control
- Packaging machinery air circuit conditioning
- Automotive assembly line tool air supply
Installation protocol:
Install vertically with filter first, regulator second, lubricator last. Maintain 50mm clearance below drain port.
Lubricator should be positioned ≤3 meters downstream from actuators. Replace filter element every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | AC40B-04E-R-B |
| Port Size | G1/2 |
