Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC40B-06G-N-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC40B-06G-N-B FRL Combination Unit Specifications
- Model: AC40B-06G-N-B
- Type: Filter-Regulator-Lubricator (FRL) with bracket
- Port size: G1/4 (BSPP thread)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 1,000 L/min (ANR)
- Filter rating: 40μm (5μm optional element available)
- Regulator accuracy: ±0.2 MPa
- Lubricator oil capacity: 70cm³
- Weight: 0.8kg (empty)
- Dimensions: 150mm(L) × 80mm(W) × 100mm(H)
- Body material: Aluminum alloy (filter bowl: polycarbonate)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Pressure gauge: 1/8" dial type (0-1.6MPa scale)
- Mounting: Panel bracket with M5 mounting holes
Integrated pneumatic conditioning unit combining automatic drainage filter, precision pressure regulator, and adjustable lubricator. Features transparent bowl with anti-burst design and pressure relief lock mechanism. The chrome-plated adjustment knob includes a tamper-proof security ring for industrial environments.
- Centralized air preparation for production line tooling
- CNC machine pneumatic system conditioning
- Automated assembly line actuator control
- Food packaging machinery (food-grade lubricant compatible)
- Plastic injection molding machine air supply
Installation note:
Install in sequence (filter → regulator → lubricator) with minimum 300mm straight inlet piping.
Drain bowl daily in high-humidity environments. Lubricator should be filled with ISO VG32 or
equivalent turbine oil, maintaining 1/3 to 2/3 bowl capacity during operation.
| Property | Property Value |
|---|---|
| sku | AC40B-06G-N-B |
| Port Size | G3/4 |
