Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC40B-06G-R-B
$346.59
Regular price
$354.09
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
AC40B-06G-R-B
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
● Enhanced Operational Efficiency
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
Installation protocol:
Install in sequence - filter first, regulator second, lubricator last.
Maintain vertical orientation with arrow marking airflow direction.
Replace filter element every 6,000 hours or when pressure drop exceeds 0.1MPa.
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC40B-06G-R-B FRL Combination Unit Specifications
- Model: AC40B-06G-R-B
- Type: 3-in-1 Filter-Regulator-Lubricator (FRL)
- Port size: PT1/4 (G1/4 thread)
- Maximum flow: 3000 L/min (ANR)
- Operating pressure range: 0.05–1.0 MPa
- Filter element: 40μm precision (5μm optional)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.6 MPa scale)
- Lubricator oil capacity: 150cm³
- Weight: 1.8 kg (dry)
- Dimensions: 198mm(W) × 150mm(H) × 120mm(D)
- Body material: Die-cast aluminum (anodized finish)
- Seal material: NBR & polycarbonate
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Manual float drain
- Mounting: Bracket with M5 mounting holes
Modular FRL unit combining 40μm particulate filtration, precision pressure regulation (±0.02MPa stability), and adjustable oil mist lubrication. Features dual-chamber design with transparent bowls for visual maintenance checks. The "R" suffix indicates right-side pressure gauge orientation.
Typical Applications:
- Pneumatic production line air preparation
- CNC machine tool pneumatic systems
- Industrial robot end-effector control
- Packaging machinery air supply conditioning
- Automotive assembly line tooling
Installation protocol:
Install in sequence - filter first, regulator second, lubricator last.
Maintain vertical orientation with arrow marking airflow direction.
Replace filter element every 6,000 hours or when pressure drop exceeds 0.1MPa.
Lubrication guidance:
Use ISO VG32 turbine oil or equivalent. Adjust oil drip rate to 1-3 drops/minute
using the needle valve (clockwise rotation reduces flow). Bowl requires monthly
cleaning in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | AC40B-06G-R-B |
| Port Size | <3/4 inch> |
