Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC40D-04DG-1-A
$631.45
Regular price
$638.95
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
AC40D-04DG-1-A
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
● Enhanced Operational Efficiency
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
Installation note:
Mount horizontally with 30cm clearance below for bowl maintenance.
Use ISO VG32 turbine oil in lubricator. Drain filter daily in humid environments.
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC40D-04DG-1-A Triple Unit (FRL) Specifications
- Model: AC40D-04DG-1-A
- Type: Filter-Regulator-Lubricator combination
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–0.9 MPa
- Max flow rate: 1,200 L/min (ANR)
- Filter grade: 40μm (replaceable element)
- Regulator accuracy: ±0.05 MPa
- Lubricator oil capacity: 150ml (with drip rate 1-60 drops/min)
- Weight: 0.85kg (dry)
- Dimensions: 160mm(L) × 85mm(W) × 135mm(H)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR
- Temperature range: -5℃ to 60℃
- Pressure gauge: 0-1.6 MPa (integrated)
- Protection rating: IP42
Integrated compressed air treatment unit combining particulate filtration (with auto-drain), precision pressure regulation, and adjustable lubrication. Features a transparent bowl with safety shield and manual drain override. The modular design allows individual component replacement.
Typical Applications:
- Pneumatic production line main air preparation
- CNC machine tool pneumatic systems
- Industrial robot end-effector supply
- Packaging machinery air circuit conditioning
- Automotive assembly tool stations
Installation note:
Mount horizontally with 30cm clearance below for bowl maintenance.
Use ISO VG32 turbine oil in lubricator. Drain filter daily in humid environments.
| Property | Property Value |
|---|---|
| sku | AC40D-04DG-1-A |
| Port Size | 1/2" |
