Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC50-06-B
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC50-06-B Triple Unit (F.R.L.) Technical Specifications
- Model designation: AC50-06-B
- Component configuration: Filter + Regulator + Lubricator (FRL)
- Thread standard: G1/4 (BSPP) / Optional NPT1/4
- Maximum pressure: 1.0 MPa (145 psi)
- Flow capacity: 2000 NL/min (at 0.7 MPa)
- Filter rating: 50 μm (mesh size)
- Pressure gauge range: 0-1.6 MPa / 0-232 psi (dual scale)
- Adjustable pressure: 0.05-0.85 MPa
- Oil droplet rate: 5-8 drops/minute (adjustable)
- Tank capacity: 130 cm³ (lubricator)
- Weight: 1.25 kg (2.76 lbs)
- Dimensions: 180mm(L) × 120mm(W) × 150mm(H)
- Material: Die-cast aluminum body, polycarbonate bowl
- Temperature range: -5℃ to 60℃ (non-freezing conditions)
- Seal material: NBR (Nitrile rubber)
Industrial-grade air preparation unit combining particulate filtration, precision pressure regulation, and adjustable pneumatic lubrication. Features dual-scale pressure gauge with shock-resistant liquid filling and bowl guard. The transparent lubricator bowl enables visual oil level monitoring, while the manual drain valve simplifies maintenance.
- Primary air treatment for CNC machine pneumatic systems
- Assembly line actuator control stations
- Packaging machinery air line conditioning
- Industrial robot end-effector supply lines
- Plastic injection molding machine air circuits
Maintenance protocol:
Drain filter bowl daily in high-humidity environments. Lubricant viscosity should match
ambient temperatures (ISO VG32 for 20℃). Install in sequence: Filter → Regulator → Lubricator.
| Property | Property Value |
|---|---|
| sku | AC50-06-B |
| Port Size | <3/4 inch> |
