Airtac Air Treatment Combination (Filter, Regulator, Lubricator) AC50B-10DG-B
$549.76
Regular price
$557.26
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
AC50B-10DG-B
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
● Enhanced Operational Efficiency
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
Installation protocol:
Install in sequence (Filter → Regulator → Lubricator) with minimum 300mm straight inlet piping.
Maintain vertical orientation (±15° tolerance). Drain bowl requires weekly inspection in humid environments.
Use ISO VG32 turbine oil for lubrication.
Integrated filter element and bowl assembly enables convenient in-hand filter replacement during maintenance
● Energy-Saving Pressure Regulator Pressure drop reduction: Up to 50% improvement
● Optimized Maintenance Space Maximum 46% space reduction
● Improved Visibility and Safety
Features a transparent bowl protector guard fully enclosing the housing
● Accessories
Partition plate: Y200-A, Y300-A, Y400-A, Y500-A
Bracket-mounted partition plate: Y200T-A, Y300T-A, Y400T-A, Y500T-A
● Customizable Specifications Added [New]
● Visual Monitoring & Safety Enhancement
Transparent guard improves fluid level observation while preventing accidental bowl detachment
● Ergonomic Maintenance
One-piece filter/bowl design simplifies servicing with tool-free disassembly
● Compact Footprint 46% space-saving vs conventional units
● Precision Pressure Regulation
Adjustable range: 0.05-0.85MPa & 0.02-0.2MPa variants
● Gauge Options
Square flush-mount gauge | Round dial gauge | Electronic pressure switch
Category: FRL Combination Units, Brand: AirTAC, Series: AC
AirTAC AC50B-10DG-B Triple Unit (F.R.L) Specifications
- Model: AC50B-10DG-B
- Type: Filter-Regulator-Lubricator Combination Unit
- Port size: G1/2 (BSPP)
- Operating pressure range: 0.05–0.85 MPa
- Maximum flow: 3,500 L/min (ANR)
- Filter rating: 5μm (with auto-drain)
- Regulator accuracy: ±0.05 MPa
- Lubricator oil capacity: 50cc (drip rate 1-120 drops/min)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR
- Temperature range: -20℃ to 70℃
- Weight: 1.2kg (dry)
- Dimensions: 180mm(L) × 120mm(W) × 120mm(H)
- Pressure gauge: 1/8" BSP dial type (0-1.0 MPa scale)
- Mounting: Bracket-integrated design
Modular FRL unit combining 2-stage filtration (5μm+40μm), precision pressure regulation (±2% FS), and adjustable lubrication. Features dual-chamber filter bowl with anti-reflow design and impact-resistant polycarbonate cover. The regulator includes a locking knob and relief vent.
Typical Applications:
- Pneumatic production line air preparation
- CNC machine tool pneumatic systems
- Industrial robot end-effector control
- Packaging machinery actuator groups
- Automotive assembly line tool stations
Installation protocol:
Install in sequence (Filter → Regulator → Lubricator) with minimum 300mm straight inlet piping.
Maintain vertical orientation (±15° tolerance). Drain bowl requires weekly inspection in humid environments.
Use ISO VG32 turbine oil for lubrication.
| Property | Property Value |
|---|---|
| sku | AC50B-10DG-B |
| Port Size | Single Acting |
