Airtac MID Series Double Rod Mini Cylinder MID10X125
The AirTAC Airtac MID Series Double Rod Mini Cylinder MID10X125 is a genuine double acting, double rod round-body mini air cylinder with a Ø10mm bore and 125mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface makes it a compact drop-in for standard mini-cylinder fixtures.
- BoreØ10 mm
- Stroke125 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod
- Rod threadM4×0.7
- CushionFixed TPU bumper pads
About the Airtac MID Series Double Rod Mini Cylinder MID10X125
Delivering 33 N of thrust at 0.5 MPa in both directions, the AirTAC MID10X125 is a double-acting, through-rod mini cylinder. Because a 4 mm rod exits both end covers, the extend and retract areas are identical, guaranteeing equal force while the twin rod resists rotation and side load for steadier guiding. The stainless-steel round barrel and rod offer mild corrosion resistance for light washdown environments.
Designed to the ISO 6432 mounting interface, this 10 mm bore unit drops into standard mini brackets. It features an M5x0.8 port and a 125 mm stroke. Based on the 0.5 MPa rating, the safe working load is about 20 N, which means it can vertically lift roughly 1.7 kg with a 2:1 safety margin. The fixed TPU bumper pads decelerate the stroke ends, though they do not lock the load.
Airtac MID Series Double Rod Mini Cylinder MID10X125 Technical Specifications
| Model | Airtac MID Series Double Rod Mini Cylinder MID10X125 |
|---|---|
| Series | MID ISO 6432 mini cylinder |
| Bore size | Ø10 mm |
| Stroke | 125 mm |
| Acting type | Double acting, double rod |
| Port size | M5×0.8 |
| Rod thread | M4×0.7 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed TPU bumper pads |
| Max standard stroke | Up to 200 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø10mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 33 N |
| 0.7 MPa | 46 N |
| Max (@1.0 MPa) | 7 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac MID Series Double Rod Mini Cylinder MID10X125
| MID | ISO 6432 round-body mini cylinder (double-rod). |
|---|---|
| 10 | Bore size in mm. |
| ×125 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MID Series Double Rod Mini Cylinder MID10X125 Is Used
Symmetric Part Shuttle
With 33 N of equal force both ways, this cylinder smoothly pushes a light 1.7 kg jig back and forth between two stations without twisting.
Back-Rod Switch Trip
The extended rear rod provides a convenient mounting point to physically trip a mechanical limit switch at the end of the 125 mm stroke.
Steady Guided Push
The twin 4 mm rods resist side load and rotation, keeping a small pressing head aligned during light assembly tasks.
Is the Airtac MID Series Double Rod Mini Cylinder MID10X125 the Right Cylinder?
If you need less force, the smaller MID8X125 provides 18.8 N at 0.5 MPa; for more push, the larger MID12X125 offers 42.4 N. This double-rod design is ideal when you need anti-rotation stability, want to use the back rod end to trip a switch or carry a stop, or need to drive a second load. Without a magnet, this specific SKU cannot take a CMSG, DMSG, or EMSG sensor—you must choose the -S variant for position sensing.
You can mount this cylinder using LB foot, FA flange, or TC trunnion brackets, plus CA, U, R, or CM back covers, but the SDB pivot-block is not available on this double-rod variant. Remember that a standard cylinder drifts if air pressure is lost. The bumpers only soften the stroke end, so use an external rod lock or pilot check valve if you must hold a load safely.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MID Series Double Rod Mini Cylinder MID10X125 FAQ
Because it is a double-rod cylinder, the force is equal both ways. It delivers 33 N at 0.5 MPa, 46.1 N at 0.7 MPa, and a maximum theoretical force of 6.7 kgf at 1.0 MPa. The air port is M5x0.8.
No, this specific SKU does not include a magnet, so it cannot take CMSG, DMSG, or EMSG sensors. You must select the -S variant for sensing. The stainless steel build resists mild corrosion.
