Airtac AirTAC MID Series Double Rod Mini Cylinder MID12X160S
2. Front/rear covers with integrated cushion rings to minimize reversing impact;
3. Versatile rear cover configurations for simplified installation flexibility;
4. Crimped structure securely connects stainless steel cylinder barrel with front/rear covers for enhanced joint reliability;
5. Stainless steel piston rod and cylinder barrel provide corrosion resistance in mildly corrosive environments;
6. Multiple specifications and mounting accessories available for diverse application needs.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MID
AirTAC MID12X160S Dual-Rod Miniature Cylinder Specifications
- Model: MID12X160S
- Type: Double-acting dual-rod cylinder
- Bore size: 12mm
- Stroke: 160mm
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: M5x0.8 (G1/8 optional)
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Mounting types: Foot mounting (standard), front flange/ rear flange (optional)
- Weight: 350g ±5% (excluding accessories)
- Dimensions: 200mm(L) × 25mm(W) × 25mm(H) (full extension length)
- Rod diameter: 4mm (both rods)
- Max theoretical force: 9.1kgf@0.5MPa
- Speed range: 50–800mm/s
- Lubrication: Pre-lubricated (relubrication interval: 2,000km)
Ultra-compact dual-rod cylinder featuring synchronized bidirectional movement and space-saving design. The chrome-plated piston rod and precision honed tube ensure smooth operation with ≤0.1mm repeat positioning accuracy. Ideal for applications requiring symmetrical force distribution and precise linear motion in confined spaces. Includes built-in magnetic sensor slots for position feedback (sensors sold separately).
- PCB handling robots in electronics assembly
- Micro-dosing mechanisms in medical devices
- Precision clamping fixtures for CNC machining
- Optical lens positioning systems
- Laboratory automation sample handlers
- Textile machinery thread guides
Installation note:
Maintain ≤0.05mm alignment tolerance between rod ends and load.
Use only ISO VG32 hydraulic oil for relubrication.
Avoid side loads exceeding 2N·m. For vertical mounting,
install rod-end locks to prevent unintended descent during air loss.
| Property | Property Value |
|---|---|
| sku | MID12X160S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 160mm |
