Airtac AirTAC P-4V Repair Kit P-4V230E-R1
AirTAC P-4V230E-R1 Repair Kit Technical Details
- Model: P-4V230E-R1
- Compatible Series: SC/SU Series Standard Cylinders (Bore 230mm)
- Components Included:
- Rod seal set (primary & secondary)
- Piston seal (U-cup design)
- Wear ring (guide band)
- O-rings (multiple sizes)
- Cushion seal (impact absorption)
- Backup rings (anti-extrusion)
- Material Composition:
- Seals: NBR (Nitrile) / PU (Polyurethane)
- Wear rings: Glass-filled PTFE
- Backup rings: Hardened Nylon
- Temperature Range: -20℃ to 80℃ (continuous operation)
- Pressure Range: 0.1 - 0.9 MPa
- Weight: 1.85 kg (complete kit)
- Package Dimensions: 320mm(L) × 180mm(W) × 45mm(H)
- Storage Humidity: ≤75% RH (non-condensing)
- Shelf Life: 5 years in original packaging
Comprehensive maintenance solution for 230mm bore pneumatic cylinders, featuring wear-resistant sealing systems with dual lip designs for enhanced pressure containment. The kit includes all critical wear components engineered to OEM specifications, using anti-static treated materials to prevent particulate adhesion in cleanroom-compatible applications.
- Recommended replacement interval: 5 million cycles or 12 months (whichever comes first)
- Requires ISO VG32-grade pneumatic oil for seal lubrication
- Compatible with both tandem and compact cylinder configurations
- Includes alignment tool for proper wear ring installation
- High-cycle injection molding machine ejectors
- Steel mill cylinder refurbishment
- Automotive welding fixture maintenance
- Paper processing equipment overhauls
Maintenance protocol:
Always perform barrel honing inspection (Ra ≤0.8μm) before installation.
Use torque-controlled wrench (12-15Nm) for end cap fasteners to prevent
seal channel deformation. Post-installation pressure test required.
| Property | Property Value |
|---|---|
| sku | P-4V230E-R1 |
