Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL12X10SFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL12X10SFB Rotary Clamping Cylinder Specifications
- Model: QCKL12X10SFB
- Type: Double-acting rotary clamping cylinder with auto-rotation mechanism
- Bore size: 12mm
- Stroke: 10mm
- Rotation angle: 90° (±5° adjustable)
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -10℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Mounting type: Standard base mount with M5 threaded holes
- Port size: M5×0.8 (Rc1/8 adaptor included)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal type: NBR seals with wear-resistant ring
- Weight: 0.32kg (excluding accessories)
- Dimensions: 78mm(L) × 34mm(W) × 34mm(H)
- Protection rating: IP54 (standard dust/moisture resistance)
Precision rotary clamping cylinder featuring integrated 90° rotation and vertical clamping motion. The twin-piston design ensures balanced force distribution, while the hardened guide slots provide smooth rotational movement. Includes anti-vibration pads for noise reduction (≤65dB) and optional magnetic sensor slots for position feedback.
- CNC machine tool fixture switching mechanisms
- Automated assembly line workpiece positioning
- Robotic end-effector tool changers
- Semiconductor wafer handling systems
- Precision mold clamping devices
Installation guidelines:
Maintain 0.5-1mm clearance between clamp arm and workpiece surface during initial setup.
Lubricate guide rails with ISO VG32 hydraulic oil monthly. Maximum lateral load capacity: 15N.
| Property | Property Value |
|---|---|
| sku | QCKL12X10SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | LH (Left-Hand) |
