Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL12X10SMFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL Rotary Clamping Cylinder QCKL12X10SMFB Technical Details
- Model: QCKL12X10SMFB
- Type: Rotary clamp cylinder with mechanical lock
- Bore size: 12mm
- Stroke: 10mm
- Rotation angle: 90°±5°
- Operating pressure: 0.1-0.8 MPa
- Clamping force: 34N at 0.4MPa
- Mounting style: Double bracket mounting (MFB type)
- Port size: M5x0.8
- Piston material: Aluminum alloy hard anodized
- Rod material: Stainless steel SUS304
- Seal type: NBR wear-resistant seals
- Temperature range: -20℃ to 80℃
- Weight: 0.25kg
- Dimensions: 78mm(L) × 34mm(W) × 34mm(H) (including stroke)
- Buffer type: Adjustable cushioning
- Protection class: IP40
- Repeat positioning accuracy: ±0.5mm
Compact rotary clamping cylinder featuring precision ground guide rods and dual ball bearing rotation mechanism. The QCKL series combines linear motion with 90-degree rotation for secure workpiece fixation. The SMFB version offers enhanced stability through its symmetrical mounting brackets and integrated T-slot for accessory attachment. Requires 40μm filtered air with ISO VG32 lubricant.
- Robotic end-effector tool changers
- CNC machine fixture positioning
- Automated assembly line pallet locking
- PCB handling equipment
- Medical device manufacturing jigs
Operation note:
Maintain 0.3-1.0 m/s piston speed for optimal bearing life. Apply grease (MLGI-2)
every 500km of cumulative travel. Avoid side loads exceeding 5N during rotation phase.
| Property | Property Value |
|---|---|
| sku | QCKL12X10SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | LH (Left-Hand) |
