Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL12X20SFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL12X20SFB Rotary Clamping Cylinder Specifications
- Model: QCKL12X20SFB
- Type: Rotary clamping cylinder (double-acting)
- Bore size: 12mm
- Stroke: 20mm
- Rotation angle: 90° ±5°
- Operating pressure: 0.1–0.9 MPa
- Clamping force: 34N at 0.5MPa
- Port thread: M5×0.8
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal type: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Weight: 0.25kg ±5%
- Dimensions:
- Total length: 72mm (extended)
- Body diameter: Φ32mm
- Mounting base: 20×20mm square pattern
- Clamp arm length: 25mm from center
Compact rotary clamp cylinder featuring precision ground guide rods and anti-rotation mechanism. The SFB variant includes a built-in magnetic sensor slot (inductive sensor not included) and shock-absorbing end caps. Requires 5μm filtered air with ISO VG32 hydraulic oil mist lubrication (1 drop/3 cycles recommended).
- PCB fixture positioning in SMT machines
- Workpiece retention in CNC milling operations
- Rotary indexing tables in assembly automation
- Medical device component alignment systems
- Packaging machine mold clamping
Installation note:
Maintain 0.5mm minimum clearance between clamp arm and workpiece surface.
Use locknuts (not included) on both ends of guide rods for angular adjustment.
Lubricate pivot points weekly with #2 lithium grease.
| Property | Property Value |
|---|---|
| sku | QCKL12X20SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | LH (Left-Hand) |
