Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL12X20SM
$43.02
Regular price
$50.52
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
QCKL12X20SM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Designed for welding environments, the piston rod undergoes QPQ treatment, providing superior anti-slag properties compared to traditional hard chrome-plated surfaces;
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
Operation note:
Maintain 0.5-1mm clearance between clamp arm and workpiece surface during initial setup.
Lubricate guide rails every 500,000 cycles using ISO VG68 way oil.
Do NOT exceed 120% rated pressure during manual override.
Always install mechanical stop blocks for overload protection.
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL Rotary Clamping Cylinder QCKL12X20SM Technical Details
- Model: QCKL12X20SM
- Type: Compact rotary clamping cylinder (90° rotation)
- Bore size: Ø12mm
- Stroke: 20mm
- Operating pressure: 0.1–0.8 MPa
- Rotation torque: 0.3 N·m (at 0.5 MPa)
- Clamping force: 42N (at 0.5 MPa)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal type: NBR + PU combination seals
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Weight: 0.45kg ±2%
- Dimensions: 85mm(L) × 34mm(W) × 34mm(H)
- Repeat accuracy: ±0.5°
- Response time: 0.3s (full rotation cycle)
Compact rotary clamp cylinder featuring precision rack-and-pinion mechanism for 90° workpiece positioning. Integrated T-slot mounting design allows direct fixture plate installation. Requires 5μm filtered compressed air with ISO VG32 lubricant (optional).
Industrial Applications:
- CNC machine tool pallet clamping
- Automated welding fixture positioning
- PCB assembly line component retention
- Robotic end-effector tool switching
- Medical device assembly jigs
Operation note:
Maintain 0.5-1mm clearance between clamp arm and workpiece surface during initial setup.
Lubricate guide rails every 500,000 cycles using ISO VG68 way oil.
Do NOT exceed 120% rated pressure during manual override.
Always install mechanical stop blocks for overload protection.
| Property | Property Value |
|---|---|
| sku | QCKL12X20SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | LH (Left-Hand) |
