Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL16X10SMFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL16X10SMFB Rotary Clamping Cylinder Specifications
- Model: QCKL16X10SMFB
- Type: Double-acting rotary clamping cylinder
- Bore size: 16mm
- Stroke: 10mm
- Operating pressure: 0.1–0.9 MPa
- Clamping torque: 0.7 N·m (at 0.5 MPa)
- Rotation angle: 90°±1°
- Operating temperature: -10℃ to 70℃
- Port size: M5×0.8 (Rc1/8 compatible)
- Buffer type: Fixed cushioning
- Material: Aluminum alloy body, CRMo steel piston rod
- Seal material: NBR
- Protection rating: IP40
- Weight: 0.48 kg
- Dimensions: 100mm(L) × 32mm(W) × 32mm(H)
- Mounting: Through-hole φ6.6 (2 places)
Compact 90° rotary clamp cylinder with precision-ground helical gear mechanism, featuring dual piston design for balanced torque output. Integrated T-slot allows direct workpiece mounting. Includes built-in magnet for position sensing compatibility (sensor not included). Requires 5μm filtered air with ISO VG32 lubricator.
- CNC machine tool fixture locking
- Automated assembly line positioning
- Robotic end-effector tool changing
- PCB handling equipment clamping
- Medical device manufacturing jigs
Operation note:
Maintain 0.5mm minimum clearance between clamp arm and workpiece surface during installation.
Lubricate pivot points with MIL-PRF-6085 grease quarterly. Maximum cycling rate: 120 cpm.
| Property | Property Value |
|---|---|
| sku | QCKL16X10SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | LH (Left-Hand) |
