Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL16X20SMFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL16X20SMFB Rotary Clamping Cylinder Specifications
- Model: QCKL16X20SMFB
- Type: Double-acting rotary clamping cylinder
- Bore size: 16mm
- Stroke: 20mm
- Operating pressure: 0.15–0.8 MPa
- Rotation angle: 90°±5° (standard)
- Port size: M5×0.8 (dual ports)
- Cushioning: Adjustable rubber buffer
- Temperature range: -20℃ to 80℃
- Body material: Aluminum alloy (piston rod: SUS304)
- Seal material: NBR (nitrile rubber)
- Clamping force: 31.4N at 0.5MPa
- Weight: 0.38kg
- Dimensions: 100mm(L) × 34mm(W) × 34mm(H)
- Mounting: Standard M6×1.0 threaded holes (4 positions)
- Protection rating: IP54 (standard)
Compact rotary clamping cylinder with integrated rotation mechanism, featuring precision-ground guide rods and anti-rotation pins for stable angular positioning. The dual-port design enables rapid clamping/release cycles (≤0.3s at 0.5MPa). Includes wear-resistant brass bushings and chrome-plated piston rod for extended service life.
- PCB fixture positioning in electronics assembly
- Workpiece clamping in CNC machining centers
- Rotary indexing tables in automated production lines
- Precision jig systems for optical component inspection
- Medical device assembly tooling
Installation note:
Apply 2-3 drops of ISO VG32 hydraulic oil monthly through air inlet.
Maintain ≤0.5mm parallelism between clamp face and mounting surface.
Requires 5μm filtered air with lubricator (recommended oil: ISOVG32).
| Property | Property Value |
|---|---|
| sku | QCKL16X20SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | LH (Left-Hand) |
