Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL16X30SM
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL Rotary Clamping Cylinder QCKL16X30SM Technical Details
- Model: QCKL16X30SM
- Type: Rotary clamp cylinder with mechanical lock
- Bore size: 16mm
- Stroke: 30mm
- Operating pressure: 0.15–0.7 MPa
- Clamping torque: 0.8–3.8 N·m (pressure-dependent)
- Rotation angle: 90°±5°
- Port size: M5x0.8 (dual ports)
- Operating temperature: -10℃ to 60℃
- Material: Aluminum alloy body, CRCA mounting bracket
- Seal material: NBR (nitrile rubber)
- Buffer type: Adjustable cushioning
- Weight: 420g ±3%
- Dimensions: 130mm(L) × 42mm(W) × 42mm(H)
- Protection rating: IP54 (standard), IP67 optional
- Mounting orientation: Any direction
Compact rotary clamping cylinder combining linear motion with 90° rotation for precision workholding. Features dual-action mechanical locking mechanism with zero backlash, optimized for high-cycle applications. Integrated T-slot design allows direct fixture mounting. Requires 5μm filtered air with ISO VG32 lubricator oil (optional oil-free operation).
- CNC machine tool pallet changers
- Robotic welding jig positioning
- Semiconductor wafer handling robots
- Automotive part assembly stations
- 3D printer bed locking mechanisms
Installation note:
Apply 2–3 N·m torque during bracket fastening. Perform 10-15 manual
test cycles before power operation. Maintain 0.5mm clearance between
clamp arm and workpiece surface.
| Property | Property Value |
|---|---|
| sku | QCKL16X30SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | LH (Left-Hand) |
