Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL16X30SMFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL Rotary Clamping Cylinder QCKL16X30SMFB Technical Details
- Model: QCKL16X30SMFB
- Bore size: 16mm
- Stroke: 30mm
- Rotation angle: 90° ±5° (clockwise/counter-clockwise)
- Operating pressure: 0.1-0.8 MPa
- Torque output: 0.8-1.2 N·m (pressure-dependent)
- Action type: Double-acting with mechanical rotation
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Piston material: Aluminum alloy with hard anodized finish
- Rod material: Stainless steel SUS304
- Seal type: NBR + PU combination seals
- Temperature range: -20℃ to 80℃
- Weight: 0.54 kg ±2%
- Dimensions: 100mm(L) × 42mm(W) × 42mm(H)
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting: Standard MF1 pattern with 4x M4 threaded holes
- IP rating: IP54 (standard) / IP67 (optional with special seals)
Precision rotary clamping cylinder combining 90° rotation with linear clamping force. Features anti-rotation guide pins for positional accuracy and dual sealing system for maintenance-free operation. The chrome-plated guide rod ensures smooth rotation even under side load conditions. Requires 5μm filtered air with ISO VG32 lubricator.
- CNC machine tool fixture positioning
- Robotic welding arm end-effector clamping
- Semiconductor wafer handling systems
- Automotive part transfer mechanisms
- Pharmaceutical blister packaging machines
Installation note:
Maintain 0.5-1mm clearance between clamp jaw and workpiece surface during initial positioning.
Lubricate rotating parts with silicone grease every 500,000 cycles. Avoid continuous rotation beyond
specified angle to prevent torsion spring fatigue.
| Property | Property Value |
|---|---|
| sku | QCKL16X30SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | LH (Left-Hand) |
