Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL20X10S
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL20X10S Rotary Clamping Cylinder Technical Details
- Model: QCKL20X10S
- Action type: Double-acting with rotary mechanism
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 10mm (±0.5mm tolerance)
- Operating pressure: 0.1-1.0 MPa
- Clamping torque: 0.8 N·m @ 0.5 MPa
- Rotation angle: 90° (±1° precision)
- Operating temperature: -10℃ to 70℃
- Cushioning: Adjustable rubber buffer
- Port size: M5x0.8 (G1/8 optional)
- Seal material: Polyurethane (NBR optional)
- Protection class: IP54 (standard dust/moisture resistance)
- Weight: 0.82 kg (without accessories)
- Dimensions: 84mm(L) × 34mm(W) × 34mm(H) (body only)
- Extended length: 94mm (stroke included)
Compact rotary clamping cylinder combining linear motion with 90° rotation, featuring precision-ground guide rods for wobble-free operation. The hardened stainless steel shaft and dual piston design ensure 50,000+ cycle durability. Requires filtered air (5-50μm) with 1-2 drops of ISO VG32 oil per m³.
- CNC machine tool fixture positioning
- Automated welding jig systems
- PCB assembly line clamping
- Robotic end-effector tool changers
- Medical device assembly stations
Installation tip:
Mount using M4 screws (max torque 1.2N·m) with perpendicularity
tolerance ≤0.1mm. Allow 15mm clearance for rotation arc. Lubricate
guide shafts monthly with silicone-free grease.
| Property | Property Value |
|---|---|
| sku | QCKL20X10S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | LH (Left-Hand) |
