Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL20X10SFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL20X10SFB Rotary Clamping Cylinder Specifications
- Model: QCKL20X10SFB
- Type: Double-acting rotary clamping cylinder with magnetic piston
- Bore size: 20mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Rotation angle: 90° (±2°)
- Clamping force: 78N at 0.5MPa
- Piston speed: 50–700mm/s
- Port thread: M5x0.8
- Buffer type: Rubber cushion (adjustable)
- Mounting style: Front flange with 4xM5 threaded holes
- Material: Aluminum alloy body, CRMo steel piston rod
- Seal material: NBR (Nitrile rubber)
- Ambient temperature: -20℃ to 80℃
- Weight: 0.54kg ±2%
- Dimensions: 150mm(L) × 60mm(W) × 60mm(H)
- Protection class: IP40 (Dust protected)
- Lubrication: Pre-lubricated (Grease G-238)
Compact rotary clamping cylinder combining linear motion with 90° rotation, featuring integrated T-slot for tooling attachment. The hardened piston rod and precision-ground guide surfaces ensure repeatability within ±0.1mm. Includes built-in magnetic field for position sensing compatibility.
- Automated fixture positioning in CNC machining centers
- Workpiece clamping in robotic welding stations
- Tool changing mechanisms in PCB drilling machines
- Precision alignment in optical component assembly
- Rotary indexing in packaging equipment
Installation note:
Maintain 0.5mm minimum clearance between clamping arm and workpiece surface.
Use Loctite 243 on mounting screws (torque ≤4.5N·m).
For vertical mounting, install exhaust mist separator to prevent oil drain.
| Property | Property Value |
|---|---|
| sku | QCKL20X10SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | LH (Left-Hand) |
