Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL20X10SM
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL Series Rotary Clamping Cylinder QCKL20X10SM Technical Details
- Model: QCKL20X10SM
- Type: Rotary clamp cylinder with mechanical lock
- Bore size: Ø20mm
- Stroke: 10mm
- Operating pressure: 0.1-0.8 MPa
- Operating temperature: -10℃ to 70℃
- Port size: M5×0.8 (standard dual ports)
- Rotation angle: 90°±5° (clockwise/counter-clockwise)
- Clamping force: 310N @0.5MPa
- Torque output: 1.5N·m max
- Buffer type: Rubber cushion (adjustable)
- Seal material: NBR + PU combination
- Weight: 0.68kg (excluding accessories)
- Dimensions: 122mm(L) × 50mm(W) × 50mm(H)
- Mounting pattern: ISO 15552 standard
- Repeat positioning accuracy: ±0.05mm
- Protection class: IP54 (standard), IP67 optional
Compact rotary clamping cylinder featuring dual-action rotary locking mechanism with position detection slots. The QCKL20X10SM combines linear piston movement with 90° rotary output, using hardened stainless steel guide rods for wear resistance. Integrated shock absorption prevents workpiece slippage during high-speed operations.
- CNC machine tool fixture positioning
- Semiconductor wafer handling robots
- Automotive welding jig locking systems
- Packaging line rotary indexing stations
- Medical device assembly tooling
Operation guidance:
Requires 5-7 bar filtered lubricated air (ISO 8573-1 class 3.4.2).
Lubricate pivot points every 500,000 cycles using ISO VG32 hydraulic oil.
Avoid side-load exceeding 30N during clamping operations.
- Magnetic switch compatibility: D-A93/D-Z73 series
- Custom stroke lengths available (5-50mm)
- Anti-rotation bracket kit (optional accessory QCKL-ARK20)
| Property | Property Value |
|---|---|
| sku | QCKL20X10SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | LH (Left-Hand) |
