Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL20X10SMFB
$56.52
Regular price
$64.02
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
QCKL20X10SMFB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Designed for welding environments, the piston rod undergoes QPQ treatment, providing superior anti-slag properties compared to traditional hard chrome-plated surfaces;
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
Installation note:
Ensure proper alignment of rotation axis with workpiece. Allow 0.5mm clearance
between clamp arm and mating surface. Lubricate pivot points every 500,000 cycles.
Critical parameters:
Max lateral load 15N·m | Do NOT exceed 1,200 cycles/hour |
Use shock absorber when stroke end impact velocity >0.5m/s
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL20X10SMFB Rotary Clamping Cylinder Specifications
- Model: QCKL20X10SMFB
- Type: Double-acting rotary clamping cylinder
- Bore size: 20mm
- Stroke: 10mm
- Operating pressure: 0.1–0.7 MPa
- Rotation angle: 90° (±5° adjustable)
- Clamping force: 62N @0.5MPa
- Port size: M5 (1/8" NPT optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal type: NBR rubber seals
- Temperature range: -10℃ to 70℃
- Weight: 0.65kg ±2%
- Dimensions: 80mm(L) × 34mm(W) × 34mm(H)
- Mounting type: Dual through-hole (M5×0.8 thread)
- Position detection: Built-in magnetic sensor slot (M9 connector)
Precision rotary clamping cylinder combining linear motion with 90° rotation for secure workpiece fixation. Features anti-rotation guide mechanism and wear-resistant coating, optimized for high-cycle applications. Requires filtered air (40μm) with ISO VG32 lubricator oil (optional).
Typical Applications:
- CNC machine tool fixture positioning
- Robotic arm end-effector tool changing
- Automated assembly line pallet locking
- Semiconductor wafer handling systems
- Medical device manufacturing jigs
Installation note:
Ensure proper alignment of rotation axis with workpiece. Allow 0.5mm clearance
between clamp arm and mating surface. Lubricate pivot points every 500,000 cycles.
Critical parameters:
Max lateral load 15N·m | Do NOT exceed 1,200 cycles/hour |
Use shock absorber when stroke end impact velocity >0.5m/s
| Property | Property Value |
|---|---|
| sku | QCKL20X10SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | LH (Left-Hand) |
