Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL20X20S
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL20X20S Rotary Clamping Cylinder Specifications
- Model: QCKL20X20S
- Type: Rotary clamping cylinder with manual unlock
- Bore size: 20mm
- Stroke: 20mm
- Operating pressure: 0.1–0.8 MPa
- Operation method: Double-acting
- Rotation angle: 90° standard (customizable to 180°)
- Mounting type: Side/Flange mounting
- Port size: M5x0.8 (1/8" PT optional)
- Cushion type: Adjustable pneumatic cushion
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 70℃
- Protection rating: IP40
- Weight: 0.82kg ±2%
- Dimensions: 120mm(L) × 20mm(W) × 20mm(H) (excluding accessories)
- Torque output: 1.2N·m at 0.5MPa
- Piston rod material: Stainless steel SUS304
- Repeat positioning accuracy: ±0.5mm
Compact rotary clamp cylinder combining linear thrust and 90° rotation for precision fixturing. Features integrated T-slot for tooling plate attachment and manual emergency release mechanism. The chrome-plated cylinder tube ensures wear resistance in high-cycle applications (up to 2 million cycles). Requires ISO 8573-1:2010 Class 3 compressed air.
- Automated welding fixture positioning
- CNC machine tool workpiece clamping
- Robotic end-effector quick-change systems
- Electronics assembly press-fit operations
- Automotive part inspection jigs
Installation note:
Maintain 0.5-1mm clearance between clamp arm and workpiece surface during initial positioning.
Lubricate pivot points with ISO VG32 hydraulic oil monthly in continuous operation environments.
| Property | Property Value |
|---|---|
| sku | QCKL20X20S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | LH (Left-Hand) |
