Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL20X20SFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL20X20SFB Rotary Clamping Cylinder Technical Details
- Model: QCKL20X20SFB
- Type: Double-acting rotary clamping cylinder
- Bore size: 20mm
- Stroke: 20mm
- Operating pressure: 0.15–0.8 MPa (1.5–8 bar)
- Rotation angle: 90°±5°
- Clamping force: 235N @ 0.5MPa
- Mounting style: Standard flange mounting (ISO 15552 compatible)
- Port size: M5×0.8 (G1/8 adaptor optional)
- Cushioning: Adjustable pneumatic cushion
- Seal material: NBR/PU combination
- Temperature range: -20℃ to +80℃
- Repeat positioning accuracy: ±0.2mm
- Protection rating: IP67 (dust/water resistant)
- Weight: 0.82kg ±3%
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H)
Precision rotary clamping cylinder with integrated T-slot for tooling plate attachment. Features anti-rotation guide rods and wear-resistant chromium-plated piston rod. The dual-chamber design allows simultaneous rotation and clamping actions, achieving 0.8-second cycle times. Requires ISO 8573-1:2010 Class 3 compressed air (max 50mg/m³ oil content).
- CNC machine tool workpiece fixturing
- Robotic welding station positioning
- Automotive engine component assembly lines
- PCB handling automation systems
- Medical device manufacturing jigs
Operation tip:
Apply 1-2 drops of ISO VG32 hydraulic oil monthly to air inlet for seal lubrication.
Avoid side-load forces exceeding 30N during rotation phase.
| Property | Property Value |
|---|---|
| sku | QCKL20X20SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | LH (Left-Hand) |
