Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL20X20SM
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL20X20SM Rotary Clamping Cylinder Specifications
- Model: QCKL20X20SM
- Type: Double-acting rotary clamping cylinder
- Bore size: Ø20mm
- Stroke: 20mm
- Operating pressure: 0.1–0.9 MPa
- Rotation angle: 90°±1°
- Clamping force: 245N @0.5MPa
- Port size: M5x0.8 (dual ports)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal type: NBR + special wear-resistant ring
- Temperature range: -10℃ to 80℃
- Weight: 0.68kg (1.5 lbs)
- Dimensions: 146mm(L) × 42mm(W) × 42mm(H)
- Mounting: Standard M6 threaded holes (4 places)
- Protection rating: IP54 (standard), IP67 optional
High-precision rotary clamping cylinder featuring integrated wedge mechanism for zero-backlash operation. The hardened guide rail structure ensures ≤0.03mm repeat positioning accuracy. Optimized for high cycle applications (up to 1,500,000 cycles) with self-lubricating bushings. Includes magnetic piston for position detection compatibility.
- CNC machine tool fixture positioning
- Automated welding jig systems
- PCB board clamping in SMT lines
- Robotic arm end-effector tooling
- Precision mold changing systems
Installation note:
Apply 0.5-1Nm torque during mounting. Requires air lubrication (ISO VG32 or equivalent)
when operating above 0.5m/s. Avoid side loads exceeding 30N.
- 5,000km travel distance (standard seals)
- 10,000km (optional heavy-duty seal kit)
- Relubrication interval: 2 million cycles or 6 months
| Property | Property Value |
|---|---|
| sku | QCKL20X20SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | LH (Left-Hand) |
