Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL20X20SMFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL20X20SMFB Rotary Clamping Cylinder Specifications
- Model: QCKL20X20SMFB
- Type: Rotary clamping cylinder with manual lock
- Bore size: 20mm
- Stroke: 20mm
- Operating pressure: 0.1–0.9 MPa
- Rotation angle: 90°±5°
- Mounting style: Side-mounted flange with M5 threaded holes
- Port size: M5×0.8 (dual ports)
- Buffer type: Rubber cushion (adjustable)
- Operating temperature: -10℃ to 80℃
- Main material: Aluminum alloy body, CRCA piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 0.68 kg (1.5 lbs)
- Dimensions: 140mm(L) × 52mm(W) × 52mm(H)
- Rotation torque: 0.8 N·m (at 0.5 MPa)
- Clamping force: 120N (at 0.5 MPa)
- Response time: ≤0.3s (at 0.6 MPa)
High-precision rotary clamping cylinder featuring dual-action piston and manual override lock mechanism. The hardened stainless steel guide shaft ensures precise 90° rotation with repeat positioning accuracy ±0.2mm. Integrated T-slot design allows direct fixture mounting without additional brackets. Requires filtered air (5-50μm) with lubrication (ISO VG32 recommended).
- CNC machine tool workpiece positioning
- Automated welding jig systems
- Robotic arm end-effector tool changing
- Electronics assembly precision clamping
- Medical device manufacturing fixtures
Installation guidelines:
Align clamping face perpendicular to workpiece surface (±0.5° tolerance).
Apply thread locker (Loctite 243 recommended) on mounting screws.
Perform 10-15 dry cycles before load operation. Lubricate every 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | QCKL20X20SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | LH (Left-Hand) |
