Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL20X30-S
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL20X30-S Rotary Clamping Cylinder Specifications
- Model: QCKL20X30-S
- Type: Single-acting rotary clamp cylinder (spring return)
- Bore size: Ø20mm
- Stroke: 30mm
- Operating pressure: 0.1–0.9 MPa
- Rotation angle: 90°±5°
- Mounting style: Standard base with M5 mounting holes
- Port size: M5×0.8 (dual ports for air connection)
- Cushioning: Adjustable rubber buffer
- Temperature range: -10℃ to 70℃
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR + PU combination
- Weight: 1.2kg ±5%
- Dimensions: 160mm(L) × 32mm(W mounting bracket) × 80mm(H)
- Clamping force: 157N @0.6MPa
- Response time: ≤0.3s @0.6MPa
Compact rotary clamp cylinder with integrated cam mechanism, designed for precision positioning and secure holding in automated systems. Features dual anti-rotation pins for enhanced stability and wear-resistant bushings for extended cycle life. Requires clean compressed air with 50μm filtration.
- Workpiece fixturing in CNC machining centers
- PCB board clamping during SMT assembly
- Automotive component positioning jigs
- Rotary index table locking mechanisms
- Medical device manufacturing tooling
Operation note:
Lubricate pivot points every 500,000 cycles using ISO VG32 turbine oil.
Maintain 0.3-0.7MPa operating pressure for optimal cam engagement.
Allow 2mm clearance for thermal expansion during installation.
| Property | Property Value |
|---|---|
| sku | QCKL20X30-S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | LH (Left-Hand) |
