Airtac APB Straight Tee Fitting APB12-M16
2、Superior flow performance enables equivalent capacity flow matching the tubing inner diameter;
3、Features quick-disconnect push-in tube connections with secure, durable hose retention mechanism;
4、Pre-applied thread sealant and M5 metric thread with integrated sealing washer ensure leak-proof threaded connections;
5、Nickel-plated brass construction enhances corrosion resistance and contamination prevention for expanded application scope.
Category: T-Type Tee Fittings , Brand: AIRTAC , Series: APB
AirTAC APB Series Male Tee Connector APB12-M16 Technical Details
- Model: APB12-M16
- Type: Male straight thread tee connector (positive type)
- Body material: Brass with nickel plating (anti-corrosion treatment)
- Thread standard: M16×1.5 (ISO 228-1 G1/8 equivalent)
- Seal material: NBR (Nitrile rubber) O-ring
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (continuous use)
- Proof pressure: 1.5 MPa
- Burst pressure: ≥3.0 MPa
- Flow coefficient (Cv): 0.45
- Weight: 48g ±2g
- Dimensions: 60mm (Total length) × 16mm (Port diameter) × 16mm (Branch height)
- Surface roughness: Ra ≤1.6μm (sealing surfaces)
- Compliance: RoHS 2.0 compliant
Precision-engineered brass tee connector with triple sealing protection, featuring a 60° inverted flare seat design for leak-free performance in high-vibration environments. The nickel-plated surface provides enhanced corrosion resistance against hydraulic oils and mild chemicals. Designed for 10,000+ connection cycles with <1% compression set.
- Pneumatic circuit branching in CNC machinery
- Modular air preparation units (FRL assemblies)
- Robotic end-effector air supply distribution
- Compressed air instrumentation systems
- Medical gas line manifolds (non-oxygen service)
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads (clockwise winding).
Tighten to 12-15 N·m torque using flank contact wrench.
Avoid overtightening which may deform NBR seals.
Perform pressure test at 110% working pressure after installation.
| Property | Property Value |
|---|---|
| sku | APB12-M16 |
