Airtac APC Threaded Quick Connect Coupling APC10-M20
Type: Male Threaded Straight Connector , Brand: Airtac , Series: APC
AirTAC APC Series Threaded Quick Connector APC10-M20 Technical Details
- Model: APC10-M20
- Type: Straight thread-to-tube quick disconnect
- Thread specification: M20×1.5 external thread (ISO 228 G1/2 optional)
- Tube compatibility: Ø10mm (3/8") OD pneumatic tubing
- Material: Nickel-plated brass body / Stainless steel spring
- Seal material: NBR (Nitrile) O-rings standard (FKM/Viton optional)
- Operating pressure: 0.05-1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Flow coefficient (Cv): 1.8
- Leakage rate: <10 cm³/min @ 0.5 MPa
- Weight: 85g ±2g
- Dimensions: 50mm(L) × 20mm(Ø) × 20mm(H) (body only)
- Installation torque: 25-30 N·m (M20 thread)
- IP rating: IP40 (protected against 1mm solids)
Heavy-duty pneumatic coupling with 360° rotatable swivel design for flexible hose routing. Features double-locking sleeve mechanism (push-pull operation) and pressure-sealed poppet valve to prevent air loss during disconnection. Anti-vibration structure maintains stable connection in mobile equipment.
- High-cycle pneumatic presses and stamping machines
- Robotic arm end effector connections
- Plastic injection molding air lines
- CNC machine tool clamping systems
- Food processing pneumatic circuits (food-grade version available)
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten).
For vertical downward tube entry, install retaining clip (sold separately).
Maximum allowable misalignment: 3° angular/1.5mm axial.
| Property | Property Value |
|---|---|
| sku | APC10-M20 |
| Insert Tube | <10mm> |
| Threaded Port | M20 |
